Raven Guidance & Steering

• Simplified, customizable widget layout.
• Ability to access settings page from inside a job.
• Map-based navigation.
• Auto field boundaries keep you organized automatically.
• Interactive field/job list and map view.
• Slingshot® ready for file transfer and remote support.
• ISO Universal Terminal and Task Controller functionality available.
• Straight A-B, A plus heading, pivot, contour, and last pass guidance.
• Multiple language support and customizable units.

• 12.1-inch high-quality display.
• Simple, customizable user interface with touchscreen controls.
• Offers repeatable accuracy.
• Moves easily from machine to machine.
• Records and stores data each day, displaying what was planted and where. Data is stored locally and on the cloud.
• Controls up to 105 virtual sections.
• Map based navigation.
• Boundary and guidance line options.
• Recommended for up to 5-product control.
• Slingshot® file transfer, remote support, and over-the-air software updates.
• Easy backup/system recovery.
• Straight A-B, A+, Pivot, Contour, and Last Pass guidance.
• ISOBUS Universal Terminal and Task Controller capabilities.

• Quick convergence time
• Sub-meter pass-to-pass accuracy
• Supports SBAS (25 cm),  GS Lite (15 cm) or Satellite GS (5 cm)
• Seamless integration
• Compact, low-profile design
• Fixed or magnetic mounting options
• Durable enclosure

• Compatible with all Raven displays
• All-in-one GNSS receiver: steering controller, GPS receiver, antenna and cellular connectivity modem.
• AFS RTK+ compatible (up to 1.5 cm accuracy)
• GPS, GLONASS, BeiDou, Galileo
• Optional dual-sim integrated cellular modem
• Easy-to-use automatic calibration
• Continuous reversing
• Compatible with ISOBUS 11783 Virtual Terminal
• Multi-lingual support

Raven's DirecSteer™ is a smart motor with internally controlled torque and electrical current, that works all while contributing to a simple, safe and silent operation. Compatible with most tractor platforms. DirecSteer™ is a smart mounted system with an easy to operate control panel and widgets. It’s compatible with CR7-Series and CR12-Series displays and RS1 or 500S with SC1.

• Engage Speed: 0 kph
• Distance to engage: The closest swath
• Min. steering speed: 0.072 kph
• Max. approach angle: 90 °
• Reverse steering
• Stays engaged when stopped
• Automatic Turning possible with upgrade unlock
